HP- HT° Corrosion Testing Equipments

Top Industrie can provide a full range of equipments for corrosion testing in high pressure, high temperature and very corrosive media, allowing you to perform in corrosion resistant alloys.

Our knowledge, based on old strong partnership with the most famous laboratories in France could help you to save time, and offering expertise and know-how for your project.

  • Pitting and crevice corrosion testing
  • Routine corrosion testing in static reactors
  • Sulfide stress cracking (SSC)
  • Constant Load Stress Corrosion Cracking
  • Hydrogen induced cracking (HIC)
  • Slow strain rate testing (SSRT) or CERT
  • Cyclic SSRT
  • Corrosion fatigue in sour environments
  • Electrochemical corrosion testing
  • Special corrosion testing
  • Hydrogen embrittlement testing

Static corrosion studies devices

Static corrosion studies device
  • WP / WT°: 250 bar / 400 ° C
  • Any type of static corrosion samples
  • Sour and non-sour media
  • Volume : 1 to 50 liters
  • MOC : Stainless, Incoloy, hastelloy, titanium...
  • Optionnal stirring
  • Easy closure equipment
  • Control and Acquisition under Labvew
  • In compliance with PED 97/23 and any standard on requirement

Sulfide Stress Cracking ( SSC )

Sulfide stress cracking

A versatile reactor for any type of static corrosion samples

  • Hydrogen Sulfide high concentration media
  • Volume : 1 to 50 liters
  • MOC : hastelloy, titanium, special coating...
  • Optionnal stirring
  • Easy closure equipment
  • Control and Acquisition under Labvew
  • In compliance with PED 97/23 and any standard on requirement

Slow Strain Rate Test (SSRT or CERT), Corrosion fatigue Test.

SSRT or CERT
  • 220 bar / 360 ° C
  • Any type of corrosion standard samples : CRT, FFL, CT, U-Bent ....
  • Radial reactor providing bigger area for sensors and gauges
  • Electrical insulation of electric tubes and passages followed by cracking RFP
  • Force sensors, displacement, stress ...
  • Tests under constant load, cyclic stress or fatigue
  • Control and Acquisition under Labvew





Constant Load SCC

Constant Load SCC
  • A device designed mainly for multi-samples reactors mutiplying the range of results
  • The creep stress is followed by DDP measurement.
  •  Accurate constant loading
  • Loading cycling on requirement
  • Easily handling and samples setting

High Pressure - High T° Corrosion Loop

High pressure High T° Corrosion Loop
  • Recirculating or multiphases test loop
  • Loop full flow mixing with continuous analysis
  • PWR environment 360°C and 200 bar. Lithium, Bore, H2 media. (Circulating pump, heater, cooler, full trace)
  • Flow: 5 to 20 Liters / hour
  • Reactor's volume 4 to 40 liters Stainless steel or Hastelloy C276
  • Control and Acquisition of various parameters through a specific development oversight Labview

High pressure / High T° Gas Corrosion

High pressure High T° Gas Corrosion



  • A taylor-made bench reactor allows testing stress corrosion by gas pressurization of  tubing sample up to 1200 bar and temperatures up to 800 °C.

  • Strain and tubing dimensions can be analyzed by sensors displacement or lasers measurements.

  • Any gas, sour or non-sour, inner or outer pressure ( colapsus)

  • The tests can be performed either by a control on the pressure (constant pressure, with ramps, steps, relaxation ...) by a control of the radius deformation or by measuring external diameter with constant or slow strain rate.
